Armor Pad 4 Ultra Thermal

Color:Black

Size and Weight

Height: 261.7 mm

Width: 166.8 mm

Depth: 14.3 mm

Weight: 834.5 grams

*Size and weight vary by configuration and manufacturing process. Actual measurements between individual products may vary. All specifications are subject to the actual product.

Thermal Imaging

Integrated ThermoVue Thermal Imaging

Thermal Resolution: 160x120

Refresh Rate: 25Hz

Pixel Pitch: 12μm

Sensitivity: <50mk

Measurable Temperature Range: -10°C to 550°C

Accuracy: ±3°C

Visualizes heat that is invisible to the naked eye, highlighting temperature contrasts.

Pre-install ThermoVue App

*ThermoVue App support and maintenance provided by ThermoVue Co., Ltd, which should be used in Armor Pad 4 Ultra Thermal.

Rugged

Splash, Water and Dust Resistant

Rated IP68 (maximum depth of 1.5 metres up to 30 minutes) under IEC standard 60529

Rated IP69K under IEC standard 60529

MIL-STD-810H Certification

*Armor Pad 4 Ultra Thermal is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of 1.5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor Pad 4 Ultra Thermal. Liquid damage not covered under warranty.

Versatile Light

1100 Max Lumens

483 LEDs

5.5W Max Power

IPX8 Waterproof

Display

10.36-inch

All-screen LCD Multi-Touch display with IPS technology

Resolution: 1200 x 2000 FHD+

Brightness: 500 nits

Corning Gorilla Glass 5

*With a rounded corners design on the display, the diagonal length of the screen is 10.36 inches when measured according to the standard rectangle (the actual viewable area is slightly smaller).

*The resolution measured as a standard rectangle, with a rounded corners design, the effective pixels are slightly less.

Processor

MediaTek Dimensity 6300

CPU: MediaTek MT6835T

CPU architecture: 8, 4 x Arm Cortex-A76 2.4GHz, 4 x Arm Cortex-A55 2.0GHz

CPU frequency: 2.4GHz

GPU: Arm Mali-G57 MC2

GPU frequency: up to 1068MHz

Storage and RAM

8GB+256GB

RAM: 8GB memory

Flash storage: 256GB storage

microSD memory card Up to 2TB

*Available storage and RAM are less than the total memory due to storage of the operating system and software pre-installed in the device.

*The Virtual Memory Expansion can be activated in Settings and adds up to 8GB of RAM. Some software may not be compatible with this feature.

*microSD card needs to be purchased separately. Recommended to use Class 10 memory cards, other memory cards are not guaranteed to be fully compatible.

Rear Camera

50MP Main Camera

SAMSUNG GN1 sensor

FOV 85°, ƒ/1.95

Photo resolution: up to 6138x8152 pixel

Video resolution: up to 1080P

Flash

Rear camera photography features

Normal Mode, Mono Mode, Beauty Mode, 50MP Mode, Portrait, Pro Mode, Slow Motion, Night Shot, Scan

AI Scene Detection, Grid line, Self Timer, Capture Mode, Scene Mode, Anti-shake, Geo-Tagging, ZSD, Sound Switch, Watermark, White Balance, ISO, Anti Flicker, Volume Key, Continuous Shot, Restore Defaults, Camping Light

Rear camera video features

2K recording	30fps
1080P recording	30fps
720P recording	30fps
480P recording	30fps

*The actual photo and video resolution may vary depending on the shooting mode.

*The camera software functions are subject to actual presence, some functions and names may vary depending on the software version.

Front Camera

32MP selfie camera

SAMSUNG GD1 sensor, 1.12µm, 4P, FOV 80.4°, ƒ/2.45

Front camera photography features

Normal Mode, Mono Mode, Beauty Mode

Grid line, Self Timer, Capture Mode, Scene Mode, Anti-shake, Geo-Tagging, ZSD, Sound Switch, Mirror Switch, Watermark, White Balance, ISO, Anti Flicker, Volume Keys, Restore Defaults, Camping Light

Front camera video features

1080P recording	30fps
720P recording	30fps
480P recording	30fps
CIF recording	30fps

*In different photo modes, the number of pixels may be slightly different, please refer to the actual situation.

*The actual photo and video resolution may vary depending on the shooting mode.

*The camera software functions are subject to actual presence, some functions and names may vary depending on the software version.

Charging and battery

11800 mAh

Built-in lithium-ion polymer battery

USB Type-C

Supports 33W fast charging

Battery Life:

Standby Time	642 Hours
Talk Time	64 Hours

*Typical value. Actual capacity may vary slightly. This capacity is the nominal battery capacity. The actual battery capacity for each individual product may be slightly above or below the nominal battery capacity.

* Non-removable battery. Removing the battery may cause damage to the device.

*Use with original charger and data cable, the max charging power can reach 66W. The actual charging power will intelligently change with different scenarios, please refer to the actual use.

Network

Supports use of dual SIM cards from different carriers

Both cards can access 5G connectivity

Both cards can access 4G connectivity simultaneously

Dual Nano SIM; either card can be set as the primary card

Supports 5G/4G/3G/2G

Supports VoNR HD calling

Supports VoLTE HD calling

Supported network bands

5G Network

Sub-6: N1/2/3/5/7/8/20/25/28/38/40/41/66/71/77/78/79

4G Network

FDD-LTE: B1/2/3/4/5/7/8/12/13/17/18/19/20/26/28A/28B/66/71

TDD-LTE: B34/38/39/40/41

3G Network

WCDMA: B1/2/4/5/8

2G Network

GSM: B2/3/5/8

*The support for 5G depends on the local carriers' network; Dual 5G/4G requires the support of local carriers services, and may not be available in all regions.

*Only supports single SIM for communication service, which means when one of the SIM cards is in calling, the other SIM card will not be able to connect.

*Only certain regions and telecom operators support VoNR.

*Only certain regions and telecom operators support VoLTE.

*Single VoNR only, you can select one SIM to enable VoNR, in the meanwhile, VoLTE is enabled by default on the other SIM. You also can choose to turn off VoNR or VoLTE.

Supports the following carriers' 5G networks

Europe
Austria	3, A1 Telekom, Magenta Telekom
Andorra	STA (Andorra Telecom)
Belgium	BASE，Orange，Proximus
Bulgaria	Vivacom
Croatia	Hrvatski Telekom, Telemach Croatia, A1 Mobile
Czech Republic	O2, Vodafone,T-Mobile
Denmark	TDC
Estonia	Elisa, Telia Eesti, Tele2
Finland	DNA, Elisa, Telia
France	Bouygues Télécom, Orange, SFR, Free
Germany	O2, Deutsche Telekom, Vodafone, 1&1
Greece	Cosmote, Vodafone, Wind
Hungary	Telekom, Vodafone,Yettel
Ireland	Eir, Vodafone, 3
Italy	TIM, Vodafone, Wind Tre, Iliad, Fastweb
Latvia	Tele2, Bite, LMT
Luxembourg	POST, Tango, Orange
Monaco	Monaco Telecom
Netherlands	Vodafone, KPN, Odido, T-Mobile
Norway	Telenor, Telia, Ice
Poland	Aero2, Orange, Play P4, T-Mobile, Plus+
Romania	Orange, Vodafone, Digi.Mobil, Telekom
San Marino	TMS
Slovakia	O2, Slovak Telekom, SWAN 4KA
Slovenia	Telekom Slovenije, Telemach
Spain	Movistar, Orange, Vodafone, Yoigo
Sweden	Tele2, Telenor, 3, Telia
Switzerland	Salt Mobile, Sunrise, Swisscom
United Kingdom	EE, O2, Vodafone, 3, Virgin Mobile
Russia	MegaFon, MTS, Tele2
Portugal	MEO, NOS, Vodafone, Nowo
Macedonia	Telekom, VIP
Lithuania	Telia, Bite, Tele2
Malta	Go, Epic, Melita
North America
Canada	Rogers Wireless, Bell Mobility, Telus, Videotron, Koodo, Public Mobile, Freedom Mobile, Virgin Plus Mobile
United States	Sprint, T-Mobile, C spire, AT&T, Google Fi, U.S. Cellular, Verizon Wireless, Cricket Wireless, GCI Wireless
South America
Brazil	Vivo, TIM,Claro, Unifique, Algar, Brisanet
Chile	Entel, Movistar, WOM, Claro
Peru	Claro, Entel, Movistar
Trinidad and Tobago	Bmobile
Dominican Republic	Claro, Altice
Guatemala	Claro, Tigo
Argentina	Claro, Movistar, Personal
Colombia	Claro, Movistar, TigoUNE, ETB, WOM
Guyana	Digicel, Cellink Plus, E-Network
Uruguay	Claro, Movistar, Antel
Mexico	Telcell, AT&T, Movistar, Altan Redes
Asia
Bahrain	stc Bahrain, Zain, Batelco
Brunei Darussalam	Progresif, DSTCom
Cyprus	Cyta, Epic MTN
Hong Kong, China	3, China Mobile, CSL, SmarTone
Iran	Hamrahe Aval, MTN Irancell
Israel	Cellcom, Golan Telecom, Hot Mobile, Partner, We4G, 019 Mobile, Pelephone, Rami Levy
Indonesia	Indosat, Telkomsel，XL Axiata
India	Airtel, BSNL, MTNL, Vi, Jio
Japan	KDDI au, NTT Docomo, Softbank, Rakuten Movile
Jordan	Umniah, Orange, Zain
Korea	SK Telecom, LG U+, KT
Kuwait	Ooredoo, STC, Zain
Kazakhstan	Altel, Tele2, Kcell
Maldives	Dhiraagu
Malaysia	Telekom Malaysia, Celcom, Digi, Maxis, U Mobile, Yes
Macao, China	CTM, China Telecom
Singapore	M1, Singtel, StarHub, SIMBA
Sri Lanka	Airtel, Dialog
Oman	Omantel, Ooredoo, Vodafone
Philippines	Globe, Smart, Dito
Qatar	Ooredoo, Vodafone
Saudi Arabia	Mobily, STC, Zain
Tajikistan	Tcell
Thailand	AIS, TrueMove H
Taiwan, China	Chunghwa Telecom, FarEasTone, Taiwan Mobile, GT, Taiwan Star
Uzbekistan	Uztelecom, Ucell, Mobiuz
United Arab Emirates	du, Etisalat
Oceania
Australia	Vodafone, Telstra, Optus
New Zealand	2degrees, Spark, Vodafone
Africa
Egypt	Etisalat, Orange, Vodafone
Gabon	Airtel, Gabon Telecom
Kenya	Safaricom
Lesotho	Vodafone
South Africa	MTN Group, Vodacom, Rain
Nigeria	Airtel, MTN
Mauritius	Emtel, Orange
Réunion	Orange, SRR (SFR), Telco OI

*This list will be continuously updated, if you have any questions, please consult the dealer.

*Last updated on July 26, 2024.

*Info collected from Kimovil.com.

Connectivity

Supports protocols: 802.11 a/b/g/n/ac

Supports 2.4G/5G

Bluetooth

Supports Bluetooth 5.2

Navigation and positioning

Supports multiple positioning systems

GPS
GLONASS
Beidou
Galileo
Digital Compass

uSmart Expansion

uSmart 2.0, Supports Endoscope and Microscope

uSmart E01

Endoscope

uSmart E02

Dual Camera Endoscope

uSmart E03

180° Endoscope

uSmart C01

Super Microscope

*For more devices that are compatible with uSmart Expansion Connector, you are recommended to refer to our accessories list. Expansion devices require additional purchases.

Supports Google Pay

Supports Transit, Loyalty Cards, Gift Cards and Plane tickets

*Supported by Google Pay, you should download Google Pay to use it. Google Pay available countries and regions please refer to https://pay.google.com/about.

Operating System

Android 14

Pure Android System

No ads

Buttons

Sensors

NFC, Side-Mounted Fingerprint，Light sensor, Gravity sensor, Acceleration sensor, Geomagnetic sensor, Gyro sensor, Coulomb counter

Multimedia

Video	MKV/3GP/MP4
Audio	MID/FLAC/MP3/M4A AAC/AMR/OGG
Image	GIF/JPEG/PNG/BMP
Ebook	TXT/HTML

Ports

USB 2.0, Type-C

3.5 mm Headphone Jack
uSmart Expansion Connector

Card slot

Three(3), Nano SIM + Nano SIM + microSD

Notification Light

Support, tri-color light, red/green/blue

Supports charging prompt

Language support

Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese

In the box

1x Ulefone Armor Pad 4 Ultra Thermal

1x AC Power Charger

1x Type-C to Type-C Data Cable (100cm)

1x Tablet Hand Strap (requires self-installation)

1x Screwdriver (used to install Hand Strap)

8x Screws (4 pre-installed on the tablet, 4 spare)

1x Protective Film (Pre-installed)

1x SIM Needle

1x Multi-language User Manual

1x Multi-function Instruction Card

1x Warranty Card

1x Charging Instruction Card

1x Safety Prompt Card

1x Service Center APP Instructions

1x Accessories Ecosystem Brochure

1xThermal Imaging User Manual Access Guide

*The AC power charger's plug type varies according to your region, with optional standard EU/AU/US plugs available.

*May vary in different market. Subject to the actual product.

*The apperance of package and accessories may be different, but the function remain the same, please refer to the actual.
